White plastic shell mesh Jack 6p4c RJ11 connector

Our strengths:

Interface type: crystal head application: 10 / 100 / 1000BASE-T Ethernet

Type: RJ45 built in magnetics

Working frequency: high frequency characteristic: filtering, anti-interference

Working temperature: 0 ℃ - 70 ℃,

Storage temperature: - 40 ℃ - 85 ℃

Lead free soldering: wave soldering height up to 265 ℃

RJ45 full series of integrated circuit accessories, RJ45 network connector manufacturer direct supply

1. Business mode: Manufacturer

2. Delivery time: on time delivery, around two weeks.

3. Specs for choices: LED indicator light(green, yellow, red, orange, blue, bi-color LED)

Shield with EMI fingers or not

coil ratio of magnetic core

magnetics circuit diversification optional

contact gold plating (FU, 3U, 6U, 15u, 30U, 50U)

plastic housing material (PBT,PA46,PA9T, LCP)

4. The electrical properties of the products meet the industry standards, the appearance and mechanical properties meet the appearance dimensions, the mechanical manufacturing industry standards, and the environmental protection standards. Your satisfaction is the purpose of our service!

Performance parameters:

1. Applied to Ethernet, coil ratio: 1CT: 1CT

2. Meet IEEE 802.3 & ANSI X 3.263 standard

3. Open circuit inductance (OCL): 350uH (MIN) @ 100kHz, 0.1VRMS with 8Ma DC Bias

4. Wave soldering process of 265 ℃ Max meeting the requirements of EU ROHS standard

5. Withstand voltage: 2250VDC 1mA max, 60s

6.Impedance: 100 ohms

7. RJ45 interface meets FCC 68.5 standard

8. DC resistance: 1.5 Ω

Parameters

Drawings

Pictures

DGKYD - An Overview

DGKYD (www.dgkyd.com) and its divisions are primarily engaged in the design, manufacture, and sale of Ethernet connectors(RJ45/RJ11) and transformers used in networking, telecommunications, high-speed data transmission, commercial aerospace, military, industrial electrical, and consumer electronics.

DGKYD development and production center located in Dong Guan of China. With over 10 years of experience, we lead the industry in R&D investment, striving to develop and deliver innovative, high-quality, reliable solutions that can be customized to meet your needs. Coupled with personalized service, few companies can approach DGKYD's responsiveness. DGKYD has reliably demonstrated the ability to succeed in a variety of product areas across multiple industries.

What does all of this really mean? Your time can be spent concentrating on network and business strategies rather than worrying about the compatibility, flexibility and viability of your telecommunications supplier.

Together, we can turn your vision into reality.

Thank you for visit. For any further information, please feel free to contact us.
